Siemens SIMATIC ET 200iSP User Manual

Technical speci󹪝cations
Article number 6ES7134-7SD00-0AB0
General information
Product type designation 4AI TC
Input current
Current consumption, typ. 17 mA
from supply voltage L+, max. 30 mA
Power loss
Power loss, typ. 0.4 W
Analog inputs
Number of analog inputs 4
Cycle time (all channels) max. 320 ms; 66 ms basic conversion time x 4 channels
with interference frequency suppression 60 Hz, 80
ms basic conversion time x 4 channels with inter‐
ference frequency suppression 50 Hz
Technical unit for temperature measurement ad‐
justable
Yes
Input ranges (rated values), voltages
• -80 mV to +80 mV
Yes
– Input resistance (-80 mV to +80 mV)
1 000 kΩ
Input ranges (rated values), thermocouples
• Type B
Yes
– Input resistance (Type B)
1 000 kΩ
• Type C
Yes
– Input resistance (Type C)
1 000 kΩ
• Type E
Yes
– Input resistance (Type E)
1 000 kΩ
• Type J
Yes
– Input resistance (type J)
1 000 kΩ
• Type K
Yes
– Input resistance (Type K)
1 000 kΩ
• Type L
Yes
– Input resistance (Type L)
1 000 kΩ
• Type N
Yes
– Input resistance (Type N)
1 000 kΩ
• Type R
Yes
– Input resistance (Type R)
1 000 kΩ
• Type S
Yes
– Input resistance (Type S)
1 000 kΩ
• Type T
Yes
– Input resistance (Type T)
1 000 kΩ
• Type U
Yes
– Input resistance (Type U)
1 000 kΩ
Analog electronic modules
14.5 Analog electronics module 4 AI TC
ET 200iSP
Operating Instructions, 11/2022, A5E00247483-AK 365
