Article number 6ES7135-7TD00-0AB0
Alarms
• Diagnostic alarm
Yes
Diagnoses
• Diagnostic information readable
Yes
• Wire-break
Yes
• Short-circuit
Yes
Diagnostics indication LED
• Group error SF (red)
Yes
Potential separation
Potential separation analog outputs
• between the channels
No
• between the channels and backplane bus
Yes
Standards, approvals, certicates
CE mark Yes
Dimensions
Width 30 mm
Height 129 mm
Depth 136.5 mm
Weights
Weight, approx. 265 g
Technical specications
Voltages, currents, electrical potentials
Electrical isolation
• Between channels and power bus
Yes
Status, interrupts, diagnostics
Interrupts
• Diagnostic interrupt
Yes, can be set
Diagnostic functions
• Group error display
Red "SF" LED
Monitoring for
• Short-circuit
I
Load
> 1 mA
R
Load
< 30...60 Ω
• Wire break
I
Load
> 1 mA
R
Load
< 0.68...24 kΩ
1
Injection of substitute values Yes, can be set
Safety information
Analog electronic modules
14.6 Analog electronic module 4 AO I HART
ET 200iSP
Operating Instructions, 11/2022, A5E00247483-AK 373
