Siemens SIMATIC ET 200iSP

Measuring ranges for voltage: ± 80 mV
Table 14-12 SIMATIC S7 format: Measuring ranges ±80 mV
Measuring range ± 80
mV
Units Range
Decimal Hexadecimal
> 94.071 32767 7FFF
H
Over󹪞ow
94.071 32511 7EFF
H
Overrange
: : :
80.003 27649 6C01
H
80.000 27648 6C00
H
60.000 20736 5100
H
: : : Nominal range
-60.000 -20736 AF00
H
-80.000 -27648 9400
H
-80.003 -27649 93FF
H
Underrange
: : :
-94.074 -32512 8100
H
< -94.074 -32768 8000
H
Under󹪞ow
Measuring ranges for current: 0 to 20 mA, 4 to 20 mA
Table 14-13 SIMATIC S7 format: Measuring ranges 0 to 20 mA, 4 to 20 mA
Measuring range
0 to 20 mA
Measuring range
4 to 20 mA
Units Range
Decimal Hexadecimal
> 23.5178 > 22.8142 32767 7FFF
H
Over󹪞ow
23.5178 22.8142 32511 7EFF
H
Overrange
: : : :
20.0007 20.0005 27649 6C01
H
20.0000 20.0000 27648 6C00
H
15.0000 16.0000 20736 5100
H
: : : : Nominal range
0.0000 4.0000 0 0
H
negative values
are not possible
3.9995 -1 FFFF
H
Underrange
: : :
1.1852 -4864 ED00
H
< 1.1852 -32768 8000
H
Under󹪞ow
Analog electronic modules
14.8 Representation of analog values
ET 200iSP
378 Operating Instructions, 11/2022, A5E00247483-AK
