Siemens SIMOCODE pro Operating Manual

Parameters
4.1 Motor protection
SIMOCODE pro - Parameterize
Operating Manual, 04/2017, A5E40507630002A/RS-AA/001
33
Adjustable responses "Overload Protection," "Unbalance Protection," and "Stalled Rotor Protection"
Response
Prewarning level
"overload protection"
Trip level "overload
protection"
Level "unbalance"
Level "stalled rotor
protection"
disabled
X
X
X
X
signaling X X X X
warn
X
X
X
X
tripping —
X
X X
delay
0 to 25.5 s (0.5 s)
—
0 to 25.5 s (0.5 s)
0 to 25.5 s (0.5 s)
Responses for "Overload Protection", "Unbalance Protection" and "Stalled Rotor Protection"
See also "Tables of responses of SIMOCODE pro" in Chapter Important information
(Page 7).
Note
Deactivate Unbalance Protection in SIMOCODE
ES when the load type is set to single-
phase!

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
