Siemens SIMOTION D410 Commissioning Manual

Table 7-6 Functions on the "Diagnostic files" HTML page
Button Function
Create general diagfiles This button saves the diagnostic data and non-volatile SIMOTION data to
the ...\USER\SIMOTION\HMI\SYSLOG\DIAG directory.
HTML files used for diagnostics purposes are not saved.
Create html diagfiles This button is used to save diagnostics HTML pages on the data carrier.
Note that only those sites that are listed in the DIAGURLS.TXT file in
directory ...\USER\SIMOTION\HMI\SYSLOG\DIAG are saved (see Section
Backup of diagnostic data and non-volatile SIMOTION data (Page 203)).
Zip all diagfiles The "zip all Diagfiles" button enables you to compress diagnostics files.
This
stores all files and folders in a ZIP file in directory ...\USER\SIMOTION
\HMI\SYSLOG\DIAG, while retaining the folder structure.
Get diagarchive This button is used to save the ZIP archive to connected programming
devices/PCs.
Delete all diagfiles This button is used to delete all data stored in the ...\USER\SIMOTION\HMI
\SYSLOG\DIAG directory; the directory itself is not removed, however.
You can find diagnostic data and non-volatile SIMOTION data on the CF card in the
directory \USER\SIMOTION\HMI\SYSLOG\DIAG.
Additional references
You will find detailed information in the
SIMOTION IT Diagnostics and Configuration
Diagnostics Manual.
7.3 Additional service and diagnostics options
7.3.1 SIMOTION Task Profiler application
The SIMOTION Task Profiler is a dedicated application installed parallel to SIMOTION SCOUT
during SIMOTION SCOUT setup. The Task Profiler can be called in online mode using device
diagnostics in SIMOTION SCOUT or the Windows application. In the event of a malfunction
or error, the Task Trace data can be written to a directory or the CompactFlash Card. They
can then be processed using the Task Trace Viewer.
Additional references
For detailed information, refer to the SIMOTION Task Trace Function Manual.
7.3.2 Diagnostics via the SIMOTION IT web server
SIMOTION D410 incorporates a Web server. As of firmware version V4.2, it is no longer
necessary to purchase licenses for the web server (IT DIAG license) and for
SIMOTION OPC‑XML.
Diagnostics data
7.3 Additional service and diagnostics options
SIMOTION D410
212 Commissioning Manual, 04/2014
