SIMOTION Utilities & Applications is part of the scope of delivery of SIMOTION SCOUT.
Table A-2
Measuring inputs - Overview of quantity structures and functionality
Maximum available quantity structure
Functionality/device D410,
CU310,
CX32
D4x5,
CU320
CX32‑2 D410-2,
CU310-2
D4x5‑2
- X122/X132
- X142
TM15 TM17 High
Feature
Maximum number of
measuring input inputs
3 6 4 8 - 8
- 8
24 16
Can be configured as a
local measuring input
x x x x - 8
- 0
- -
Can be configured as a
global measuring input
x x x x - 8
- 8
x x
A.3 Configuring local measuring inputs
Properties
Local measuring inputs are always permanently assigned to an axis (drive). They are
configured separately for each drive. The drive and the probe input must always be located
on the same control unit. The measurement results are transferred using the axis message
frame in accordance with the PROFIdrive profile. Message frame 39x does not need to be
configured for local measuring inputs.
The settings for the use of the local measuring inputs must be made in the expert list.
Procedure
To use an I/O terminal on the SIMOTION D410 or SINAMICS Control Unit as a measuring
input, proceed as follows:
1. Double-click on the "Inputs/outputs" entry below the Control Unit in the project navigator.
2. Configure the desired I/O terminal as input in the "Bidirectional digital I/Os" tab. The
configuration can also be set channel-granular on the p0728 parameter using the expert
list of the control unit.
The specification of the measuring input terminal must be performed at the local measuring
inputs in the expert list of the respective drive (refer to the following table).
Table A-3 Local measuring inputs, required settings in the expert list of the drive
Parameters in the expert list of the drive Parameterization as
D410, CU310 CU320
p0488[0]
(measuring input 1 input terminal, encoder 1)
DI/DO 9 or
DI/DO 10 or
DI/DO 11
DI/DO 9 or
DI/DO 10 or
DI/DO 11 or
DI/DO 13 or
P0488[1]
(measuring input 1 input terminal, encoder 2)
Configuring drive-related I/Os (without symbolic assignment)
A.3 Configuring local measuring inputs
SIMOTION D410
Commissioning Manual, 04/2014 217
