Parameters in the expert list of the drive Parameterization as
D410, CU310 CU320
p0488[2]
(measuring input 1 input terminal, encoder 3)
DI/DO 14 or
DI/DO 15
p0489[0]
(measuring input 2 input terminal, encoder 1)
p0489[1]
(measuring input 2 input terminal, encoder 2)
p0489[2]
(measuring input 2 input terminal, encoder 3)
Since a maximum of three encoders can be assigned to a drive, the index [0...2] specifies
whether the measurement applies to encoder 1, 2, or 3.
The following must be taken into account:
●
Two Measuring Input TOs can be configured per Axis TO or External Encoder TO.
● Only one Measuring Input TO can be active on an Axis TO or External Encoder TO.
Table A-4 Local measuring inputs, configuration of the Measuring Input TO
Axis measuring
system no.
Under axis measuring system number, enter the number of the used encoder
system (namely, encoder 1, 2 or 3). Encoder system 1 is the default setting.
Drive-related (local
measuring input)
Activate the checkbox when a local measuring input is used.
Measuring input
number
Enter here which measuring input is used (namely, 1 or 2). Input 1 is the
default setting.
Detailed information can be found in the
SIMOTION Motion Control Output Cams and
Measuring Inputs
Function Manual.
Configuring drive-related I/Os (without symbolic assignment)
A.3 Configuring local measuring inputs
SIMOTION D410
218 Commissioning Manual, 04/2014
