Procedure
1.
Save and compile the project.
2. Click "Connect to selected target systems" to establish a connection to the target system.
3. Execute "Download project to target system" and then "Copy RAM to ROM" to download
the upgraded project to the CF card as well.
4. Because of the automatic follow-up configuration in the SINAMICS Integrated drive, you
must now execute "Load CPU / drive unit to PG".
5. Save the project.
Note
When upgrading SINAMICS drive units (e.g. SINAMICS Integrated) only the p parameters
(setting parameters) are loaded into the upgraded project. The r parameters (monitoring
parameters) are not loaded.
The r parameters in the drive unit are derived or calculated from an automatic subsequent
parameterization and must therefore be uploaded to the project.
To do this, execute "Load CPU/drive unit to PG".
If the upload cannot be performed, this can lead to inconsistencies in the drive
parameterization dialog boxes.
6.5 SIMOTION CompactFlash Card
6.5.1
Replacing the CompactFlash Card
Requirement
NOTICE
Damage to the CompactFlash card from electrical fields or electrostatic discharge
The CompactFlash card is an ESD-sensitive component.
De-energize the SIMOTION D410 device before inserting or removing the CompactFlash
card. The SIMOTION D410 is in a de-energized state when all the LEDs are OFF.
Comply with the ESD rules.
Maintenance and service
6.5 SIMOTION CompactFlash Card
SIMOTION D410
194 Commissioning Manual, 04/2014
