● A DIAGURLS.TXT file containing the standard web pages is automatically created if you
have not stored your own DIAGURLS.TXT file.
●
Standard web pages are entered "without" specifying a path (e.g. "devinfo.mcs" for the
standard web page "devinfo.htm").
● User web pages (such as "user.htm") in the \USER\SIMOTION\HMI\FILES directory on the
CF card must contain the FILES/ path specification.
● If you have created subfolders (e.g. "myfolder" in the FILES directory), these must also
appear in the path.
● Only 1 file name may be used per line.
● Empty lines are not permitted (an empty line will be interpreted as the end of the list).
● No distinction is made between upper-case and lower-case letters.
● It does not matter whether you use "\" or "/" in the path name.
6,027,21,7VWDQGDUGZHESDJHV
6
,027,21,7XVHUGHILQHGZHESDJHV
Figure 7-5 Depiction of DIAGURLS.TXT editor
7.2.4 Deleting/restoring non-volatile SIMOTION data
Requirement
The diagnostic data and non-volatile SIMOTION data has been backed up to the CF card, see
Section Backup of diagnostic data and non-volatile SIMOTION data (Page 203).
Diagnostics data
7.2 Diagnostic data and non-volatile SIMOTION data
SIMOTION D410
Commissioning Manual, 04/2014 209
