5.14.3 Automatic position controller setting
Introduction
In the "Automatic Controller Setting" screen form, you can select the drive unit and the drive
for which you want to perform automatic DSC position controller setting. The steps required
for
this calculation can be performed via this screen form. The calculated Kv value is displayed
and can then be accepted online in the configuration data of the axis that is assigned to the
drive.
Prerequisites
In addition to the general prerequisites for automatic controller setting, the following boundary
conditions apply for setting the position controller:
● DSC is required for position controller setting.
Note
Activate
the project setting "Use symbolic assignment" and select the Standard/Automatic
option for the axis-drive communication when configuring the drives. You automatically
use DSC for the servo drives with these settings.
● The speed controller must have already been configured (e.g. using automatic speed
controller setting).
●
One axis must be connected to the SINAMICS drive (servo).
● An online connection to the SIMOTION device must be established to transfer the results
of automatic position controller setting.
● The balancing filter is not changed.
● For operation without precontrol, the equivalent time constant of the position controller must
be adjusted manually by the user (PostionTimeConstant = 1/Kv).
● Vibration on the load side is not taken into account for position controller setting.
Procedure
To perform automatic setting of the position controller, proceed as follows:
1. Select the "Target System" > "Automatic Controller Setting" menu command.
2. Select the drive unit and the drive (axis).
3. Select the "Position controller (DSC)" from "Controller Selection".
4. Click "Assume control priority" to assume control priority.
5. Click the "Drive ON" button to enable the drive.
Perform the steps either in automatic mode or as individual steps.
6. Select the axis data sets to which the Kv factor is to be transferred.
7. Click "Accept values" to transfer the calculated Kv factor to the axis data sets.
8. Disable the drive by clicking the "Drive OFF" button.
Commissioning (software)
5.14 Optimizing the drive and controller
SIMOTION D410
144 Commissioning Manual, 04/2014
