Additional references
Further information on the topic of "Going online" can be found
●
In the online help via the "Contents" tab at
– "Diagnostics" > "Overview of service and diagnostics options" > "Part III" > "Go online"
– "Insert device and connect to target system" > "Go online/offline"
● On the Internet at Internet address (
http://support.automation.siemens.com/WW/view/en/
22016709)
●
In SIMOTION Utilities & Applications, FAQ "Online connections to SIMOTION devices".
SIMOTION Utilities & Applications is part of the scope of delivery of SIMOTION SCOUT.
4.2.4 Configuring the Ethernet PG/PC interface (only for D410 PN)
Prerequisites
The following requirements must be satisfied in order to configure the PG/PC interface:
● You have closed the "Insert SIMOTION device" dialog box by pressing "OK" and configured
the properties of the PROFINET interface
● A PG/PC has not yet been configured in the project.
If these prerequisites have been satisfied, you can configure the interface for the PG/PC
connection in the "Interface selection ‑ D410" dialog box.
Proceed as follows to configure the PC Ethernet interface:
Parameter assignment / addressing
4.2 Creating a project and configuring the communication
SIMOTION D410
58 Commissioning Manual, 04/2014
