5.2 Configuring the system in offline mode
5.2.1 Overview
Introduction
In the case of offline configuration, the project is created while not all of the hardware
components (in particular drives) are available. In this way, a SIMOTION project in the office
environment can be created up to a point where a basic project specification including a
program exists. At a later time, the finished project can then be loaded to the SIMOTION D410
and tested together with the drive.
Prerequisites for offline configuration
● All components and their order number must be known for the offline configuration.
● You created a project in SIMOTION SCOUT and added a SIMOTION D410 to the project.
● You configured the communication between the programming device / PC and SIMOTION
D410.
Procedure
The offline configuration involves the following steps:
● For details regarding calling up the Drive Wizard, see Section Accessing the drive wizard
(Page 82)
● For configuring components, see Section Configuring the components (Page 82)
● Downloading the project to SIMOTION D410, by means of the following options:
– For downloading to the target system, see Section Downloading the project to the target
system (Page 89)
– For downloading to the CF card, see Section Loading a project created offline to the
CompactFlash Card (Page 90)
– For downloading incl. sources and additional data, see Section Downloading the project
incl. sources and additional data (Page 91)
– For archiving a project, see Section Archiving a project on the CompactFlash Card (zip
file) (Page 92)
Note
During offline configuration, you can configure Terminal Modules such as the TM15,
for example.
Commissioning (software)
5.2 Configuring the system in offline mode
SIMOTION D410
Commissioning Manual, 04/2014 81
