16.
Use this softkey or the curso
r keys to search for the following machine data and assign the
desired values:
•
30130[0] = 1
•
32260 = the rated motor speed
•
35000 = 2
17.
Press this softkey to activate the value changes. Note that the control system restarts to a
c-
cept the new values and the additional spindle can be used in the sy
stem.
Note
The factory default PLC program only supports one additional axis.
Setting parameters for the additional analog spindle
Proceed as follows to set the parameters for the additional analog spindle:
+
1.
Select the system data operating area.
2.
Open the channel machine data window through th
e following softkey operations:
→ →
3.
Use this softkey or the cursor keys to search for the following machine data and a
ssign the
desired values:
•
For the turning variant of the control system:
– 20070[3] = 5
– 20080[3] = SP2
•
For the milling variant of the control system:
– 20070[4] = 5
– 20080[4] = SP2
4.
Open the general
machine data window and set 10000[4] = MSP2.
5.
Pre
ss this key to return to the higher-level menu.
6.
Open the basic machine data window.
7.
Use this sof
tkey or the cursor keys to search for "14512 USER_DATA_HEX[20]".
8.
Select "Bit2" and "Bit3" by using this key and the cursor keys.
9.
Press this softkey to confirm your input.
10.
Press this softkey to activate the value changes. Note that the control system restarts to a
c-
cept the new values.
