Siemens SINUMERIK 808D ADVANCED Commissioning Manual

Commissioning Manual
01/2017
397
Order No.
1PH110...
1-1❑F
3-1❑F
5-1❑F
3-1❑D
5-1❑D
Rated frequency
53.3 Hz
53 Hz
52.6 Hz
36.9 Hz
36.4 Hz
Rated voltage (phase/phase)
326 V
290 V
327 V
269 V
265 V
Motor maximum voltage
355 V
Rated current
10.3 A
16.9 A
19.6 A
12.9 A
18.8 A
Maximum current (for maximum torque)
20.6 A
33.8
39.2
25.8
37.6
Winding resistance/stator phase re-
sistance (20°C)
0.9682 Ω 0.4595 Ω 0.3597 Ω 0.8227 Ω 0.4557 Ω
Winding inductance/motor magnetizing
inductance
97 mH 56 mH 54.5 mH 91 mH 69.5 mH
Moment of inertia
0.009 kgm
2
0.0112 kgm
2
0.015 kgm
2
0.0112 kgm
2
0.015 kgm
2
Motor weight
29 kg
36 kg
45 kg
36 kg
45 kg
Specific technical data - SH132
Order No.
1PH113...
1-1❑F
3-1❑F
1-1❑D
3-1❑D
Insulation class
F
Rated power
11 kW
15 kW
7.5 kW
11 kW
Rated torque
70 Nm
95.5 Nm
71.6 Nm
105 Nm
Maximum torque for 30 s
140 Nm
191 Nm
143 Nm
210 Nm
Overload torque (S6-25% (1.5 Pn))
105 Nm
143 Nm
107 Nm
158 Nm
Rated speed
1500 rpm
1500 rpm
1000 rpm
1000 rpm
Maximum speed
8000 rpm
8000 rpm
6000 rpm
6000 rpm
Rated frequency
51.5 Hz
50.8 Hz
35.2 Hz
35 Hz
Rated voltage (phase/phase)
295 V
317 V
220 V
301 V
Motor maximum voltage
355 V
Rated current
28.8 A
36.7 A
26.6 A
28.3 A
Maximum current (for maximum torque)
57.6 A
73.4 A
53.2 A
56.6 A
Winding resistance/stator phase resistance
(20°C)
0.1977 Ω 0.1354 Ω 0.2645 Ω 0.2705 Ω
Winding inductance/motor magnetizing induct-
ance
45.55 mH 34.7 mH 52.5 mH 69 mH
Moment of inertia
0.0547 kgm
2
0.074 kgm
2
0.0504 kgm
2
0.074 kgm
2
Motor weight
73 kg
90 kg
70 kg
90 kg
Power deratings at different installation altitudes and surrounding air temperatures
Operation: T = -15 °C to +40 °C (without restriction)
Under conditions other than those specified above (surrounding air temperature > 40 °C or installation altitude > 1000 m
above sea level), the permissible torque/power must be determined from the following table. Surrounding air temperatures
and installation altitudes are rounded off to 5 °C or 500 m respectively.
Installation altitude above
sea level (m)
Power deratings (kW)
< 30 °C
30 °C to 40 °C
45 °C
50 °C
55 °C
1)
1000
1.07
1.00
0.96
0.92
0.87
1500
1.04
0.97
0.93
0.89
0.84
2000
1.00
0.94
0.90
0.86
0.82
2500
0.96
0.90
0.86
0.83
0.78
3000
0.92
0.86
0.82
0.79
0.75
3500
0.88
0.82
0.79
0.75
0.71
4000
0.82
0.77
0.74
0.71
0.67
1)
Only permitted for the non-drive end to drive end direction of air flow
