Commissioning Manual
01/2017
413
No.
Name
Default
Range
Type
Unit
Activating
31020
ENC_RESOL[0
]
10,000 DWORD - PO
Encoder lines per revolution
31030
LEADSCREW_
PITCH
10.000000 ≥ 0 DOUBLE mm PO
Pitch of leadscrew
31040
ENC_IS_DIRE
CT
FALSE, FALSE - BYTE - PO
Direct measuring system (no compilation to load position)
31050
DRIVE_AX_RA
TIO_DENOM[0]
... [5]
1 1 to
2,147,000,000
DWORD - PO
Denominator load gearbox
31060
DRIVE_AX_RA
TIO_NUMERA[
0] ... [5]
1 1 to
2,147,000,000
DWORD - PO
Numerator load gearbox
32000
MAX_AX_VEL
O
10,000
(mm/min)
27.77 (rpm)
- DOUBLE mm/min, rpm CF
Maximum axis velocity
32010
JOG_VELO_R
APID
10,000
(mm/min)
27.77 (rpm)
- DOUBLE mm/min, rpm RE
Rapid traverse in JOG mode
32020
JOG_VELO
•
Feed axis:
2,000
(mm/min)
• Spindle:
100 (rpm)
- DOUBLE mm/min, rpm RE
Jog axis velocity
32060
POS_AX_VEL
O
10,000
(mm/min)
27.77 (rpm)
- DOUBLE mm/min, rpm RE
Initial setting for positioning axis velocity
32100
AX_MOTION_D
IR
1 -1 to 1 DWORD - PO
Traversing direction (not control direction)
32110
ENC_FEEDBA
CK_POL[0]
1 -1 to 1 DWORD - PO
Sign actual value (control direction)
32200
POSCTRL_GAI
N[0] ... [5]
1.000000 0.000000 to
2000.000000
DOUBLE User defined CF
Servo gain factor
32250
RATED_OUTV
AL[0]
100 0.0 to 200 DOUBLE % CF
Rated output voltage
32260
RATED_VELO[
0]
2,000.0 - DOUBLE rpm CF
Rated motor speed
