Siemens SINUMERIK 808D ADVANCED Commissioning Manual

Commissioning Manual
414 01/2017
No.
Name
Default
Range
Type
Unit
Activating
32300
MAX_AX_ACC
EL[0] ... [4]
• Feed axis:
1.0
• Spindle:
– [0]...[2]:
10
– [3]...[4]:
2.778
≥ 0.001 DOUBLE mm/s
2
, rev/s
2
CF
Maximum axis acceleration
32450
Backlash[0]
0.0
-
DOUBLE
mm
CF
Backlash
32700
ENC_COMP_E
NABLE[0]
0 - BOOL - CF
Encoder/spindle error compensation
34000
REFP_CAM_IS
_ACTIVE
1 - BOOL - RE
Axis with reference point cam
34010
REFP_CAM_DI
R_IS_MINUS
0 - BOOL - RE
Approach reference point in minus direction
34020
REFP_VELO_S
EARCH_CAM
5,000.0
(mm/min)
13.88 (rpm)
- DOUBLE mm/min, rpm RE
Reference point approach velocity
34040
REFP_VELO_S
EARCH_MARK
ER[0]
300.0 (mm/min)
0.833 (rpm)
- DOUBLE mm/min, rpm RE
Creep velocity
34050
REFP_SEARC
H_MARKER_R
EVERSE[0]
0 - BOOL - RE
Direction reversal to reference cam
34060
REFP_MAX_M
ARKER_DIST[0
]
20.0 - DOUBLE mm, degrees RE
Maximum distance to reference mark
34070
REFP_VELO_P
OS
10,000.00
(mm/min)
27.77 (rpm)
- DOUBLE mm/min, rpm RE
Reference point positioning velocity
34080
REFP_MOVE_
DIST[0]
-2.0 - DOUBLE mm, degrees RE
Reference point distance
34090
REFP_MOVE_
DIST_CORR[0]
0.0 - DOUBLE mm, degrees RE
Reference point offset/absolute offset
34092
REFP_CAM_S
HIFT
0.000000 - DOUBLE mm RE
Electronic cam offset for incremental measuring system
