Siemens SINUMERIK 808D ADVANCED Commissioning Manual

Commissioning Manual
01/2017
415
No.
Name
Default
Range
Type
Unit
Activating
34093
REFP_CAM_M
ARKER_DIST[0
]
0 - DOUBLE mm PO
Reference cam/reference mark distance
34100
REFP_SET_PO
S[0] ... [3]
0.0 - DOUBLE mm, degrees RE
Reference point for incremental system
34200
ENC_REFP_M
ODE[0]
1 0 to 8 BYTE - PO
Referencing mode
34210
ENC_REFP_ST
ATE[0]
0 0 to 3 BYTE - IM
Adjustment status of the absolute encoder
34220
ENC_ABS_TU
RNS_MODULO
[0]
-1 1 to 100000 DWORD - PO
Modulo range for the rotary absolute encoder
34230
ENC_SERIAL_
NUMBER[0]
0 - DWORD - PO
Encoder serial number
35010
GEAR_STEP_
CHANGE_ENA
BLE
0 - BOOL - RE
Parameterize gear stage change
35100 *
SPIND_VELO_
LIMIT
10,000.0 - DOUBLE rpm PO
Maximum spindle speed
35110
GEAR_STEP_
MAX_VELO[0]
... [5]
[0]...[1]: 500
[2]: 1,000
[3]: 2,000
[4]: 4,000
[5]: 8,000
- DOUBLE rpm CF
Maximum speed for gear stage change
35120
GEAR_STEP_
MIN_VELO[0]
... [5]
[0]...[1]: 50
[2]: 400
[3]: 800
[4]: 1,500
[5]: 3,000
- DOUBLE rpm CF
Minimum speed for gear stage change
35130
GEAR_STEP_
MAX_VELO_LI
MIT[0] ... [5]
[0]...[1]: 500
[2]: 1,000
[3]: 2,000
[4]: 4,000
[5]: 8,000
- DOUBLE rpm CF
Maximum speed for gear stage
