; Softkey definition in the dialog
HS1=("")
HS2=("")
HS3=("")
HS4=("")
HS5=("")
HS6=("")
HS7=("")
HS8=("")
VS1=("")
VS2=("")
VS3=("")
VS4=("")
VS5=("")
VS6=("")
VS7=("Next Mask")
VS8=("EXIT")
; Definition LOAD block
LOAD
; Read value with RNP
ACHS_NAM1 = RNP("$MC_AXCONF_GEOAX_NAME_TAB[0]")
ACHS_NAM2 = RNP("$MC_AXCONF_GEOAX_NAME_TAB[1]")
ACHS_NAM3 = RNP("$MC_AXCONF_GEOAX_NAME_TAB[2]")
; Output of a dialog line
DLGL("Value R2: = " << RNP("$R[2]"))
; Write WNP to a value
WNP("$R[3]",VAR0)
; Vertical dividing line
V_SEPARATOR(360,1,6,1)
; Horizontal dividing line
H_SEPARATOR(220,1,7,1)
END_LOAD
; Press method
PRESS(VS7)
; Load an additional dialog
LM("MASK2")
; End identifier press method
END_PRESS
; Press method
PRESS(VS8)
Getting Started
2.2 Project example
SINUMERIK Integrate Run MyScreens (BE2)
Programming Manual, 12/2017, 6FC5397-1DP40-6BA1 19

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
