Q_OBJECT
Q_PROPERTY(double CUSVAR1 READ cusVar1 WRITE setCusVar1);
....
....
}
7.4.5 Interaction between custom widget and dialog box - Manual data exchange
Besides automatic data exchange, manual data exchange is also possible. Data exchange is
dynamic, i.e. takes place while the dialog box is running. The following actions are possible:
● Properties of the custom widget can be read and written.
● Methods of the custom widget can be called from the Run MyScreens configuration.
● A response to a particular signal of the custom widget can be implemented in order to call
subprograms (SUB) in the Run MyScreens configuration.
7.4.5.1 Reading and writing properties
Description
The functions ReadCWProperties and WriteCWProperties are provided in the Run MyScreens
configuration for reading and writing properties of the custom widgets.
Programming
Syntax:
ReadCWProperty ("Variablename", "Propertyname")
Description: Reading a property of a custom widget
Parameters: Variablename Name of a dialog box variable to which a custom widget
is assigned
Propertyname Name of the custom widget property to be read
Return value: Current value of the custom widget property
Syntax:
WriteCWProperty ("Variablename", "Propertyname", "Value")
Description: Writing the property of a custom widget
Graphic and logic elements
7.4 Custom widgets
SINUMERIK Integrate Run MyScreens (BE2)
210 Programming Manual, 12/2017, 6FC5397-1DP40-6BA1

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
