Variables not utilized in NC code during code generation are stored as user comment. The
term "user comment" refers to all information required to recompile codes. User comment must
not be altered.
Note
The block consisting of NC code and user comment can be recompiled only if it starts at the
beginning of a line.
Examples:
The programm contains the following NC code:
DEF VAR1=(I//101)
OUTPUT(CODE1)
"X" VAR1 " Y200"
"X" VAR1 " Y0"
END_OUTPUT
The following code is then stored in the parts program:
;NCG#TestGC#\cus.dir\aeditor.com#CODE1#1#3#
X101 Y200
X101 Y0
;#END#
The Editor reads the following during recompilation:
X101 Y200
X222 Y0 ; The value for X has been changed in the part program (X101 → X222)
The following value is displayed for VAR1 in the input dialog: VAR1 = 222
See also
Generate code (GC) (Page 159)
6.3.34 Recompile without user comment
Description
In the Programming Support, it is possible to recompile without user comments the NC code
that has been generated with the GC function and to display the variable values in the input/
output field of the associated entry dialog again.
Programming commands
6.3 Functions
SINUMERIK Integrate Run MyScreens (BE2)
Programming Manual, 12/2017, 6FC5397-1DP40-6BA1 177
