; Load method
LOAD
H_SEPARATOR(230,1,7,1)
END_LOAD
; Change method
CHANGE(VAR5)
; Function PI_START
PI_START("/NC,201,_N_SETUFR")
; End identifier change method
END_CHANGE
; Press method
PRESS(RECALL)
; Return to the calling mask
LM("MASK1")
; End identifier press method
END_PRESS
; Press method
PRESS(VS7)
; Return to the calling mask
LM("MASK1")
; End identifier press method
END_PRESS
; Press method
PRESS(VS8)
; Exit the dialog to the standard application
EXIT
; End identifier press method
END_PRESS
; Dialog end identifier
//END
2.2.3 Saving the configuration file in the OEM directory (example)
Storage path
Save the configuration file diag.com under the following path:
[System oem directory] /proj
Getting Started
2.2 Project example
SINUMERIK Integrate Run MyScreens (BE2)
Programming Manual, 12/2017, 6FC5397-1DP40-6BA1 21

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
