12.2.13 Configuring the "Details" window
<DETAILSCONFIGURATION> tag
In the tag <DETAILSCONFIGURATION>, you can make the settings for the "Detail" window:
Entries Meaning
ShowToolNumber The tool number is displayed in the upper right field of the "Detail" window.
UseAxisNameInLength The tool length is displayed with axis identifiers, for example, Length X
instead of Length 1.
If no data is specified, then the setting is taken from the tool lists.
ShowBaseLength The basic length is displayed in the "Detail" window (AdaptLength1,
AdaptLength2 and AdaptLength3).
If no data is specified, then the setting is taken from the tool lists.
ShowYAxis The Y axis is displayed in the "Detail" window.
If no data is specified, then the setting is taken from the tool lists.
AutoDisplayAxisEnabled Several components of the tool length are displayed, even if only one
tool length is displayed in the tool list.
Example
<DETAILSCONFIGURATION>
<ShowToolNumber value="true" type="bool" />
</DETAILSCONFIGURATION>
12.2.14 Assigning a name for magazines and magazine locations
<MAGAZINEPLACENAMECONFIGURATION> tag
The entries to assign dedicated magazine location names are located in the
<MAGAZINEPLACENAMECONFIGURATION> tag. Magazine locations can be displayed with
texts. Instead of the identifier, e.g. 1/5 for the first magazine, location five, the configured text
is then output in the tool lists.
Entries Meaning
MAGAZINE_XXX XXX stands for the magazine number.
PLACE_XXX XXX stands for the location number.
Name Text identifier of the magazine location.
Example
<MAGAZINEPLACENAMECONFIGURATION>
<MAGAZINE_9998>
Tool management
12.2 Configuring the user interface
SINUMERIK Operate (IM9)
208 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
