Column properties are modified via the variable identifier in the definition line and the column
index (starting at 1).
Example: VAR1[1].st="Column 1"
The wr, ac and li attributes can be specified for column definitions.
See also
Load Grid (LG) (Page 167)
7.3.3 Focus control in the table (cell)
Description
The Row and Col properties can be used to set and calculate the focus within a table:
● Identifier.Row
● Identifier.Col
Programming
Each cell in a table has the Val and Vld properties.
In order to read and write cell properties, a line and column index must be specified in addition
to the variable identifiers from the definition list.
Syntax: Identifier[Line index, column index].val or
Identifier[Line index, column index]
Description: Val properties
Syntax: Identifier[Line index, column index].vld
Description: Vld properties
Example
Var1[2,3].val=1.203
If the line and column indices are not specified, the indices of the focused cell apply. This
corresponds to:
Var1.Row =2
Var1.Col=3
Var1.val=1.203
Graphic and logic elements
7.3 Table description (grid)
SINUMERIK Integrate Run MyScreens (BE2)
Programming Manual, 12/2017, 6FC5397-1DP40-6BA1 205

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
