Programming
Identifier: OPTION_MD
Syntax: Area 0:
<option_md name = "Address identifier of the data" />
OR:
<option_md name = "Address identifier of the data" index= "0"/>
Area 1 to 3:
<option_md name = "Address identifier of the data" index= "Area index"/>
Attributes: name Identifier for the address, e.g. $MN_USER_DA‐
TA_INT[0]
index Identifier for the area index:
0 (default setting): Device 1 to 16
1: Device 17 to 32
2: Device 33 to 48
3: Device 49 to 64
2.7.4 PLC_INTERFACE
Description
This identifier permits the PLC ↔ HMI interface to be redefined. The system expects 128
addressable words.
Note
The identifier is not preset and must be defined by the programmer.
Programming
Identifier: PLC_INTERFACE
Syntax: <plc_interface name = "Address identifier of the data" />
Attributes: name Identifier for the address, e.g. "plc/mb170"
Example: plc/mb170
Generating commissioning dialogs
2.7 Script language
Easy XML
192 Programming Manual, 12/2017, 6FC5397-1DP40-6BA1

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
