Configuring the system
2.5 Configuration of the Service Center
PCU-Basesoftware (IM8)
Commissioning Manual, 02/2014, 6FC5397-1DP40-4BA0
73
2.5
Configuration of the Service Center
2.5.1
Overview
You can permanently adapt the settings for the backup and restoration of disk images
(Service Center (Page 87) component) in the "Service Center Backup/Restore" dialog box:
Configuration of the network adapter (Page 74)
Configuration of the host (Page 76)
Adaptations that you make here are stored in the
servicesystem.ini configuration file.
You can also adapt the settings directly in the associated configuration files:
servicesystem.ini
Additional settings for the Service System on the USB flash drive:
ghost.ini
You can also view the log files of the Service Center or restart the PCU 50.5 in the Service
Center in the "Service Center Backup/Restore" dialog box.
To open the dialog box, click the ServiceCenter Backup-Restore icon on the Desktop.
Figure 2-3 ServiceCenter Backup/Restore
