See also

Please refer to the following section for the procedure to create language-dependent text:

Creating OEM texts (Page 228)

12.2.15 Configuring the "Assign Tooltips for Multitool Locations" window

<MULTITOOLPLACETOOLTIPCONFIGURATION> tag

You will find the entries for assigning tooltips in the tag

<MULTITOOLPLACETOOLTIPCONFIGURATION>. This is particularly useful if all the

multitools used on a turning machine have two locations and a fixed assignment between

multitool locations and the main spindle or the counter spindle exists, for example,

location 1 - main spindle location 2 - counter spindle. In this case, the tooltip for location 1

could be "Tool Holder for Main Spindle."

Entries Meaning

PLACE_XXX XXX stands for the multitool location number.

Tooltip Text identifier of the magazine location.

Example

<PLACE_1>

</PLACE_1>

<PLACE_2>

</PLACE_2>

</MULTITOOLPLACETOOLTIPCONFIGURATION>
