3.12 Program selection
3.12.1 Displaying the softkey
The softkeys on the user interface for calling the program lists are activated via general
configuration machine data.
Configuring a softkey
MD51041 $MNS_ENABLE_PROGLIST_USER
0 No softkey
1 The "Prog. list" softkey is displayed
MD51043 $MNS_ENABLE_PROGLIST_MANUFACT
0 No softkey
1 The "MANUFACTURER" softkey is displayed
Precondition
To create program lists, you require the following authorization:
● "Program manager" operating area: Access level 3 (password: User) or
● "Start-up" operating area: Access level 1 (password: Manufacturer).
Program lists
You can create a program list by combining desired programs from the NC data, e.g.
workpieces, part programs and subprograms. These programs can then be selected by the
PLC for execution.
Program lists Directory
plc_proglist_user.ppl /user/sinumerik/hmi/plc/programlist
plc_proglist_manufacturer.ppl /oem/sinumerik/hmi/plc/programlist
Procedure
1. Select the "Start-up" operating area if you have the authorization for ac‐
cess level 1 (password: Manufacturer).
- OR -
General settings
3.12 Program selection
SINUMERIK Operate (IM9)
46 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
