Principles of start-up
2
2.1 Data structure of SINUMERIK Operate
For SINUMERIK Operate, all files are saved on the CompactFlash card (NCU) or to the hard
disk (PCU/IPC) or DVD (PC).
The file system is at the uppermost level:
● On the NCU in the "/System CF-Card/" directory
● On the PCU/IPC in the directory "C:\Program Files (x86)\Siemens\MotionControl"
● On the PC, the drive can be freely selected, e.g. "C:\Programs\siemens\sinumerik
The directory structure comprises the following directories:
● addon
● compat (PC/PCU/IPC only)
● oem
● siemens
● user
These directories have essentially an identical structure.
Note
The files in the “siemens” directory represent the original status and cannot be modified!
Files, whose contents can be supplemented or modified, are available as templates (specimen
files) in the following directories:
Files Directory
Configuration files /siemens/sinumerik/hmi/template/cfg
Text files /siemens/sinumerik/hmi/template/lng
Before making any changes/supplements, these files should be copied into the /cfg or /lng in /
oem/sinumerik/hmi/, /addon/sinumerik/hmi/ or /user/sinumerik/hmi/ directories.
Structure
The section of the directory structure relevant for SINUMERIK Operate is shown below:
siemens directory
/siemens/sinumerik
/hmi
/appl // applications (operating areas)
/base // basis system components
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 21
