Deleting elements
1. Place the cursor on the desired element and press the "Delete element"
softkey.
2. Press the "OK" softkey to confirm the deletion.
The selected object is removed.
12.6.3 Parameterizing the tool management
12.6.3.1 Create tool unit
A tool unit is the grouping of tools and magazines to form a unit. A tool unit can be assigned
one or more channels. The tools and magazines must be unique within a tool unit. For a tool
unit, specify the search parameters and the channel in the "TO unit" window.
Directory values
You are currently located under the "Active data" → <tool unit> directory in the "Commissioning"
→ "NC" →"Tool management" operating area.
You can set the following parameters in the "TO unit" window from the tool unit directory:
Parameters Description
Name Designation that is displayed in the tree structure.
Channel number The channel to which the tool unit is assigned.
Tool search Search strategy:
● Without search strategy
● Active tool
● Shortest way
Empty location search Search strategy:
● Without search strategy
● First location forwards
● Current location forwards
● Current location backwards
● Last location backwards
● Symmetric current location
● 1:1 exchange
Tool management
12.6 Editor for the tool and magazine management
SINUMERIK Operate (IM9)
248 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
