Note
Sequence
The specified sequence in the configuration file must be maintained.
Example:
//S (START) ; Definition of the start softkey (optional)
....
//END
//M (.....) ; Definition of the dialog
DEF ..... ; Definition of the variables
LOAD ; Description of the blocks
...
END_LOAD
UNLOAD
...
END_UNLOAD
...
//END
//S (...) ; Definition of a softkey menu
//END
Storage location for configuration files
The configuration files are located in the [System user directory] /proj directory and also
correspondingly stored in the [System add_on directory] and [System oem directory]
directories.
Converting texts from other HMI applications
Procedure to convert a text file with code page coding to text-coding UTF-8:
1. Open the text file on a PG/PC in a text editor.
2. When saving, set the UTF-8 coding.
The read-in mechanism via code page code is still supported.
Fundamentals
3.1 Structure of configuration file
SINUMERIK Integrate Run MyScreens (BE2)
30 Programming Manual, 12/2017, 6FC5397-1DP40-6BA1

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
