Siemens SINUMERIK 840D sl Commissioning Manual

Parameter: x x-coordinate, top left
y y-coordinate, top left
w Width
h Height
f1 Color of the border
f2 Fill color
s Border style:
1 = solid
2 = dashed
3 = dotted
4 = dashed and dotted
ELLIPSE element
Programming:
Syntax: ELLIPSE(x,y,w,h,f1,f2,s)
Description: Defines an ellipse or circle
Parameter: x x-coordinate, top left
y y-coordinate, top left
w Width
h Height
f1 Color of the border
f2 Fill color
s Border style:
1 = solid
2 = dashed
3 = dotted
4 = dashed and dotted
A circle is created when the values for height and width are the same.
V_SEPARATOR element
Programming:
Syntax: V_SEPARATOR (x,w,color,pen)
Description: Defines a vertical dividing line
Parameter: x x position
w Line weight
color Color
pen Line style:
1 = solid
2 = dashed
3 = dotted
4 = dashed and dotted
Graphic and logic elements
7.1 Line, dividing line, rectangle, circle and ellipse
SINUMERIK Integrate Run MyScreens (BE2)
194 Programming Manual, 12/2017, 6FC5397-1DP40-6BA1

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
