Parameters: GraphVarName Name of the display variable which contains a SlEs‐
GraphCustomWidget
Return Value Error code (bool): TRUE = successful
ContourName Name of the contour (QString).
If a contour is not specified, then the call automatically
refers to the currently selected contour.
Note
This function automatically refreshes the display.
moveCursorOnContourNext – position the cursor to the next graphic object of a contour
Syntax: ReturnValue = CallCWMethod (GraphVarName, " moveCursorOnContourNext ")
ReturnValue = CallCWMethod (GraphVarName, " moveCursorOnContourNext ",
ContourName)
Description: Starting from the actual cursor position within a contour, using this function you
can navigate the cursor to the next point object of a contour.
Parameters: GraphVarName Name of the display variable which contains a SlEs‐
GraphCustomWidget
Return Value Error code (bool): TRUE = successful
ContourName Name of the contour (QString).
If a contour is not specified, then the call automatically
refers to the currently selected contour.
Note
This function automatically refreshes the display.
moveCursorOnContourBack – position the cursor to the previous graphic object of a contour
Syntax: ReturnValue = CallCWMethod (GraphVarName, " moveCursorOnContourBack ")
ReturnValue = CallCWMethod (GraphVarName, " moveCursorOnContourBack ",
ContourName)
Description: Starting from the actual cursor position within a contour, using this function you
can navigate the cursor to the previous point object of a contour.
Parameters: GraphVarName Name of the display variable which contains a SlEs‐
GraphCustomWidget
Return Value Error code (bool): TRUE = successful
ContourName Name of the contour (QString).
If a contour is not specified, then the call automatically
refers to the currently selected contour.
Graphic and logic elements
7.5 SIEsGraphCustomWidget
SINUMERIK Integrate Run MyScreens (BE2)
244 Programming Manual, 12/2017, 6FC5397-1DP40-6BA1

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
