Parameters: GraphVarName Name of the display variable which contains a SlEs‐
GraphCustomWidget
SIGARG[0] left-hand edge (double)
SIGARG[1] upper edge (double)
SIGARG[2] right-hand edge (double)
SIGARG[3] lower edge (double)
Example
DEF MyGraphVar = (W///,"slesgraphcustomwidget.SlEsGraphCustomWidget"/////
10,10,340,340/0,0,0,0)
SUB(on_MyGraphVar_ViewChanged
DLGL("Current view: " << SIGARG[0] << ", " << SIGARG[1] << ", " << SIGARG[2]
<< ", " << SIGARG[3]
END_SUB
Graphic and logic elements
7.5 SIEsGraphCustomWidget
