Siemens SINUMERIK 840D sl Commissioning Manual

Commissioning the system
1.2 User administration
PCU-Basesoftware (IM8)
20 Commissioning Manual, 02/2014, 6FC5397-1DP40-4BA0
Example: Specific user settings
The settings under "Global Settings" are inherited by all users:
1. Left-click the user in the "Users" list.
2. After entering the password, you can adapt the settings as required.
The settings that cannot be changed are displayed with a gray background.
Figure 1-8 Specific settings for the "HMI (user.group)" user

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
