Siemens SINUMERIK 840D sl Commissioning Manual

Commissioning the system
1.4 BIOS settings for PCU 50.3
PCU-Basesoftware (IM8)
Commissioning Manual, 02/2014, 6FC5397-1DP40-4BA0
35
Hardware options
Fan control
Enabled
CRT/LCD selection
Simultan. Auto
Menu: Advanced
System parameters
Default settings
Own entries
Installed O/S
Other
Reset configuration data
No
Legacy USB support
Disabled
USB controller restart
Enabled
I/O Device Configuration
Internal COM 1
Enabled
Base I/O address
3F8
Interrupt
IRQ 4
PCI Configuration
PCI device slot 1
Option ROM scan
Enabled
Enable master
Enabled
Latency timer
Default
PCI device slot 2
Option ROM scan
Enabled
Enable master Enabled
Latency timer
Default
SATA/PATA Configuration
PATA Controller: Enabled
SATA Controller mode
Enhanced
AHCI Configuration
Disabled
RAID support
Disabled
Menu: Security
System parameters
Default settings
Own entries
Supervisor password is
Disabled
User password is
Disabled
Set user password
Enter
Set supervisor password
Enter

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
