3. Make the required settings here:
Section Settings Purpose
Base parame‐
ters
Source file Select the disk image from which the partition is to be restored.
You can use local disk images or disk images stored in the net‐
work.
Destination par‐
tition
Select the partition to be restored from the disk image.
Base parame‐
ters > Destina‐
tion partition
Connect share Open the "Connect a Share" dialog box (Page 137).
You can manage a shared resource (e.g. a directory in the net‐
work), to use a disk image stored on the network to restore the
SSD.
Select source Open the "Select source file" dialog box.
You can navigate through a local directory on the PC system
and select a disk image for restoration.
4. To start the restore process and entirely replace the existing data on the partition with the
disk image, confirm the settings with "Restore".
Result
The restore process is started.
Note
Troubleshooting if reading in of the disk image fails
If data transfer is interrupted during the restore process, the PC system will have no executable
system.
In this case, use a bootable USB flash drive with Service Center to read the disk image in
again.
Backing up and restoring data
6.8 Restore a disk image of a partition
PCU Base Software (IM10)
136 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
