Siemens SINUMERIK 840D sl Commissioning Manual

<!-- **** For all tool types *** -->
<TOOLTYPE_ALL>
<!-- **** Display tool location type *** -->
<Item value="ToolPlaceSpec" type="QString" />
</TOOLTYPE_ALL>
<!-- **** For all multitools *** -->
<TOOLTYPE_9997>
<!-- **** Display for all multitool location types *** -->
<Item value="MultiToolPlaceSpec" type="QString" />
</TOOLTYPE_9997>
</COLUMN8>
</INSERT_COLUMN>
</SlTmToolmagazinForm>
</LISTCONFIGURATION>
Example 2: Configuring the magazine list - "Oversized tool" column is deleted
Note
The columns of the list configuration cannot be taken from the display in the user interface in
all cases because some columns are automatically inserted and therefore not included in the
count of the configuration.
<LISTCONFIGURATION>
<!-- **** Magazine list *** -->
<SlTmToolmagazinForm>
<!-- **** Delete column 7 *** -->
<DELETE_COLUMN>
<COLUMN7 />
</DELETE_COLUMN>
</SlTmToolmagazinForm>
</LISTCONFIGURATION>
Example 3: Enabling the OEM tool data list
<SlTmTooloemForm>
<Enabled value="true" type="bool" />
</SlTmTooloemForm>
Tool management
12.2 Configuring the user interface
SINUMERIK Operate (IM9)
180 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
