Siemens SINUMERIK 840D sl Commissioning Manual

addon directory
/ico1280 // icons in resolution 1280x1024
/ico1600 // icons in resolution 1600x1240
/lng // text files
/lngs // text files zipped and versions files
/proj // EasyScreen configuring
/template // various templates
oem directory
/oem/sinumerik
/data // version data
/archive // manufacturer archive
/hmi
/appl // applications (operating areas)
/cfg // configuration files
/data // version data
/hlp // online help files
/hlps // online help files, zipped and version files
/ico // symbol files
/Ico640 // icons in resolution 640x480
/ico800 // icons in resolution 800x600
/ico1024 // icons in resolution 1024x768
/ico1280 // icons in resolution 1280x1024
/ico1600 // icons in resolution 1600x1240
/lng // text files
/lngs // text files zipped and versions files
/proj // EasyScreen configuring
/template // various templates
user directory
/user/sinumerik
/data // version data
/archive // user-specific archive
/prog // user-specific programs
/hmi
/cfg // configuration files
/data // version data
/hlp // online help files
/ico // symbol files
/Ico640 // icons in resolution 640x480
/ico800 // icons in resolution 800x600
/ico1024 // icons in resolution 1024x768
Principles of start-up
2.1 Data structure of SINUMERIK Operate
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 23

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
