Procedure
1. Select the "Diagnostics" operating area.
2. Press the "Version" softkey.
It takes some time to call the version display. While the version data is
being determined a progress message box and the appropriate text are
displayed in the dialog line.
3. Select the "OEM applications /manufacturer cycles" areas and press the
"Details" softkey.
The "Manufacturer Cycles" window opens.
The "Planned-actual comparison" softkey is selected by default.
See also
Save information (Page 433)
Logbook (Page 436)
Technologies and cycles
21.11 Compare cycles version
SINUMERIK Operate (IM9)
652 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
