Note
Display problems
The default settings function for most of the applications.
In exceptional cases, display problems can occur in applications with Borland-Delphi
development, i.e. shifted windows, etc.
Use the following parameters in this case:
nUnShowMode = 0
fKeepPlacement = 1
or
nInitShowMode = 1
fWinForms
Windows Forms parameters provide control elements to applications which also use Windows
default applications, e.g. dialog boxes, menus and buttons.
If the OEMFrame application is a Windows Forms application, then the following
parameterization is required:
[<app-name>]
fWinForms = 1
Note
Deactivated size adjustment
If the parameter fWinForms is not set, the OEMFrame application does not open to the
maximum size. The specified size adjustments (x, y, Width and Height) are deactivated.
nSwitchToTaskAfterTermination
This parameter controls the behavior when the OEMFrame application is exited. Normally in
this situation, the system manager displays the operating area switchover, which can be used
to switch over to another area.
The parameter nSwitchToTaskAfterTermination can be used to initiate an automatic
switch to the previously active area:
nSwitchToTaskAfterTermination
= -1
Display of the operating area switchover (default)
= -2
Switchover to the previously active area
Example
When the "closeapp.exe" Windows application is exited, a switch should be made to the
previous area. The following parameter assignment is required:
SINUMERIK Operate on PC/PCU
23.2 Parameterizing the OEMFrame application
SINUMERIK Operate (IM9)
674 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
