Property Meaning
accessLevel
Access level from which the menu item is displayed:
System, Manufacturer, Service, Customer, Key_3, Key_2, Key_1, Key_0
or numerical equivalent (0-7)
Default: Key_0 (7)
menuItemStyle
Style of the menu item that defines all visual properties of the menu item.
Note
All of the properties described below can be specified for configuring the
respective menu items as well as for defining the MenuItemStyles. An
entry in the menu item overwrites the corresponding entry in the MenuI‐
temStyle.
textSize
2)
Font size
textAlignment
2)
Alignment of the text of the menu item:
Left, Right, Top, Bottom, TopLeft, TopRight, BottomLeft, BottomRight
(analog Qt::Alignment)
You can also specify the values of the Qt flag field in hex (0x00) or dec‐
imal.
Default: Qt::AlignCenter
imageAlignment
2)
Alignment of the icon of the menu item:
Left, Right, Top, Bottom, TopLeft, TopRight, BottomLeft, BottomRight
(analog Qt::Alignment)
You can also specify the values of the Qt flag field in hex (0x00) or dec‐
imal.
Default: Qt::AlignCenter
width
2)
Width of the menu item in pixels.
Default behavior:
The menu items equally share the available space in the menu (horizon‐
tal menu) less spacing, or are as wide as the menu minus the margin
(column menu).
For grid menus, the menu items equally share height and width.
height
2)
Height of the menu item in pixels.
Default behavior:
The menu items equally share the available space in the menu (vertical
menu) less spacing, or are as tall as the menu minus the margin (row
menu).
For grid menus, the menu items equally share height and width.
color
2)
Color of the menu item.
See paragraph "Color definitions".
Default: Qt::lightGray
pressedColor
2)
Color of the menu item in the pressed state.
See paragraph "Color definitions".
Default: Qt::blue
textColor
2)
Color of the menu item text
See paragraph "Color definitions".
Default: Qt::black
General settings
3.14 Display Manager
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 59

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
