Function name Description
Load Item The function inserts a list of expressions into the control.
The function is only available for the control types "listbox" and "graph‐
icbox".
Syntax:
<function name="control.loaditem"> control name,
list </function>
Attribute:
name – function name
Values:
control name – control name
list- string variable
Structure of the list:
The list contains a number of expressions, which must be separated
from one another using a \n.
Example:
<let name="item_string" type="string"></let>
<let name="plotlist" type="string"></let>
…
…
<print name ="item_string" text="p; %f; %f; %f; %f\
\n">s_z, s_x</print>
<op>plotlist = plotlist + item_string</op>
<print name ="item_string" text="l; %f; %f;
%f; %f\\n">s_z, s_x, e_z, e_x </print>
<op>plotlist = plotlist + item_string</op>
<op> s_x = e_x </op>
<op> s_z = e_z</op>
<op> e_x = s_x + 10 </op>
<op> e_z = s_z - 100 </op>
<print name ="item_string" text="l; %f; %f;
%f; %f\\n">s_z, s_x, e_z, e_x </print>
<op>plotlist = plotlist + item_string</op>
<function name="control.loaditem">_T"gbox",
plotlist</function>
Generating user dialogs
1.10 Predefined functions
Easy XML
124 Programming Manual, 12/2017, 6FC5397-1DP40-6BA1

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
