NC Commissioning with HMI Advanced
11.7 Digital and analog I/O devices
Manual
Commissioning Manual, 05/2008, 6FC5397–4CP10–4BA0
477
Number Name Name
10530 COMPAR_ASSIGN_ANA_INPUT_1 Hardware assignment of NC analog inputs for comparator byte
1
10531 COMPAR_ASSIGN_ANA_INPUT_2 Hardware assignment of NC analog inputs for comparator byte
2
10540 COMPAR_TYPE_1 Parameterization for comparator byte 1
10541 COMPAR_TYPE_2 Parameterization for comparator byte 2
Channelspecific ($MC_ ... )
21220 MULTFEED_ASSIGN_FASTIN Assignment of input bytes of NC I/Os for "multiple feedrates in
one block"
Setting data
Table 11-55 Digital and analog I/Os: Setting data
Number Name Name
General ($SN_ ...)
41600 COMPAR_THRESHOLD_1 Threshold values for comparator byte 1
41601 COMPAR_THRESHOLD_2 Threshold values for comparator byte 2
Interface signals
Table 11-56 Digital and analog I/Os: Interface signals
DB number Bit, byte Name
General Signals from PLC to NC
10 0, 122, 124, 126, 128 Disable digital NC inputs
10 1, 123, 125, 127, 129 Setting on PLC of digital NC inputs
10 4, 130, 134, 138, 142 Disable digital NC outputs
10 5, 131, 135, 139, 143 Overwrite mask for digital NC outputs
10 6, 132, 136, 140, 144 Setting value from PLC for the digital NC outputs
10 7, 133, 137, 141, 145 Setting mask for digital NC outputs
10 146 Disable analog NC inputs
10 147 Default mask for analog NC inputs
10 148-163 Setting value from PLC for the analog NC inputs
10 166 Overwrite mask for analog NC outputs
10 167 Default mask for analog NC outputs
10 168 Disable analog NC outputs
10 170-185 Setting value from PLC for the analog NC outputs
Signals from NC to PLC
10 60, 186-189 Actual value of digital NC inputs
10 64, 190-193 Setpoint of digital NC outputs
10 194-209 Actual value of analog NC inputs
10 210-225 Setpoint of analog NC outputs
