Description
3.6 Combined operation
Operating with the Local User Interface
48 Operating Manual, 06/2017, A5E31930478-05
Table 3- 10 Plug & Measure - Installation/replacement of a PM
Data synchronization/Action
New Un-
changed
The PM electronics is replaced. "-" is
displayed instead of the serial number.
At least one AM remains in the device.
Automatic data synchronization
1)
, no
action required by user.
When there are two AMs in the device,
the new PM always synchronizes with
AM1.
The PM receives the data of the previ-
ously used PM, including its serial
2)
New Un-
changed
PM electronics with new serial number
is installed.
Automatic data synchronization
1)
, no
action required by user.
In this scenario, the replacement of the
PM electronics results in a loss of data
of the previously installed PM. In addi-
tion, the serial number is overwritten.
Data synchronization: PM parameters are transferred to the AMx (x=1 or 2), parameters of the
AMx are transferred to the PM
2)
Serial number stored in the PM is also the serial number of the device
Table 3- 11 Plug & Measure - Replacement of a PM/Installation of a used AM
Data synchronization/Action
Re-
placed
Re-
placed
Assembly from inventory: Each module
has a serial number and has been
connected to another module before.
AM of the same type is replaced.
User action. Confirm with <ENTER> or
reject with <ESC>.
When the process is confirmed, stored
AM data is transmitted to the replaced
AM.
Re-
placed
Re-
placed
Assembly from inventory: Each module
has a serial number and has been
connected to another module before.
AM of a different type is replaced.
Automatic data synchronization
1)
, no
action required by user. Each module
retains its data.
Data synchronization: PM parameters are transferred to the AMx (x=1 or 2), parameters of the
AMx are transferred to the PM
