Checking the operating voltages 3
Low voltages 3
Check the operating voltages for the SIREMOBIL Iso-C against the values in table 1.
I.I. Voltages 3
The voltages E1 / E2 / E3 and A may be taken from the I.I. test protocol and checked or
adjusted against the control test points listed in table 2.
from test point to test point Voltage Potentiometer
D1.X31 (0V) D1.X30 (+5 V) + 5.0 V to
5.2 V
M14. +5 V/Adj.
D1.X34 (0V) D1.X32 (+15 V) + 14.9 V to
15.1 V
M14. +15 V/Adj.
D1.X34 (0V) D1.X33 (-15 V) - 14.8 V to
- 15.2 V
M14. -15 V/Adj.
D30.X1.8 (0V) D30.X1.9 (+24 V) + 24.0 V to
29.6 V
not adjustable
D30.X21.1 (0V) D30.X21.10 (+24 V) + 22.8 V to
+ 29.5 V
not adjustable
D30.X20.1 (0V) D30.X20.3 (+27 V) + 27.3 V to
+ 27.8 V
D30 R115
M13.S- (0V) M13.S+ (+13 V) + 13.1 V to
13.3 V
M13.TR1
Tab. 1
Voltage Test point Ground
point
(0V)
Potentiome-
ter for full
format
Potentiome-
ter for zoom
format
Voltage
divider
ratio
E1 UE1 P10 P11 1:1
E2 UE2 P6 P7 1:1
E3 UI 15 P2 P3 1:10000
30 kV, Anode UI 30 P1 P1 1:10000
Tab. 2
