Replacing boards / replacing components 6 - 13
Siemens AG SPR2-230.061.01 Page 13 of 48 SIREMOBIL Iso-C
Medical Solutions Rev. 13 12.04 CS PS 24 System Manual
Removal 6
VIDEOMED DC 6
• Move the I.I. into the service position. Refer to chapter 1, I.I. service position.
• Remove the Videomed DC and place it on a clean surface.
• Cover it to prevent contamination. Refer also to chapter 6, VIDEOMED DC.
I.I. mini voltage supply 6
• Remove the I.I. mini voltage supply and lay it down on a suitable surface
(Control section and high voltage section).
• Refer to chapter 6, Replacing the I.I. mini voltage supply.
• Dissipate any residual voltage in the cables by shorting them to ground.
• Remove the O-ring and the cap nut from the anode cable.
• Remove the plug for the cassette contact.
• Disconnect all the cables (protective conductor, cable to VIDEOMED DC, etc.....) from
the I.I.
• At the same time, remove the cable ties or the cable clamps.
• Pull all the cables inside the C-arm.
Risk of injuries on mechanical parts!
If not observed, slight to medium injuries, especially to the hands,
can occur.
Observe the notes concerning the C-arm carbon fiber structure.
Risk of injury!
Noncompliance can lead to light to medium injuries and/or
property damage.
The C-arm covers contain counterbalance weights and weigh
approx. 6 kg.
Hold the covers firmly when installing or removing them.
Before the C-arm cover will be loosened, the C-arm must be
moved to its middle orbital position.
If the C-arm covers are loosened, the C-arm may not be moved to
its orbital end positions (I.I. or SIREPHOS at the orbital end posi-
tion).
WARNING
CAUTION
