5 - 12 Adjustments / Programs
• Select "5. CLOSED POSITION" on the service PC and click on "Execute".
• Close the status window by clicking on the OK button.
• For the query "Do you want to reset the Unit", click "NO".
• Select "8. Init Off & Store Positions" on the service PC and click on "Execute" .
• Close the status window by clicking on the OK button.
• For the query "Do you want to reset the Unit", click "Yes".
• Switch the SIREMOBIL Iso-C OFF and ON.
• Check the X-Iris again in survey format and zoom format. The collimator blades must still
be visible on the edge of the image. If necessary, repeat the adjustment.
• Return to the main menu on the service PC with the ESC key.
• Select the Data, Backup... menu.
• Select Parameter in the backup window.
• Click on "Backup".
• At "Remarks for Parameter" enter "X-Iris set".
• Click on "OK" . The new position values for the collimator will be stored on the disk.
• Return to the main menu with the ESC key.
Collimator, slot diaphragm 5
Prerequisites 5
• Camera rotation has been adjusted correctly.
• Image reversal functions are disabled.
• The "SLOT DIAPHRAGM", "TYPE OF DIAPHRAGM" parameter has been programmed
for "DISPLAY YES".
Adjustment 5
• Connect the service PC to the serial service interface.
• Start the service program.
• Select the Adjustment, Calibrations...menu.
• Respond to the query with yes.
• In the Combo box "Function Groups:" select "Slot Diaphragm".
• In the window "Available Functions:" select "Disable circle mask" and click "Execute.
The circle mask of the Memoskop is switched off.
• Close the status window by clicking on the OK button.
• Respond to the query "Do you want to reset the unit" by clicking "No" .
• In the window "Available Functions:" select "Init" and the "Execute".
• Close the status window by clicking on the OK button.
• Respond to the query "Do you want to reset the unit" by clicking "No" .
