SIREMOBIL Iso-C SPR2-230.061.01 Page 14 of 30 Siemens AG
System Manual Rev. 13 12.04 CS PS 24 Medical Solutions
5 - 14 Adjustments / Programs
Concluding steps 5
• Switch off the system and switch it back on again.
• Return to the main menu by pressing ESC at the service PC.
• Select the "Data, Backup..." menu.
• Click "parameter" in the Backup window.
• Then click "Backup" .
• Enter "slot diaphragm adjusted" under "Remarks for Parameter".
• Then click "OK" . The new position values are stored to disk.
• You can now exit from the service program.
Collimator displays on the monitor 5
Prerequisites 5
• Camera rotation, collimators for X-Iris and slot diaphragm must be set correctly.
Collimator display, X-Iris 5
• Connect the service PC to the serial interface of the SIREMOBIL.
• Start the service program.
• Select the "Adjustment, Calibrations..." menu.
• Respond to the query with "Yes".
• Select "Screen Display COLLIMATOR" in the "Function Groups:" combo box.
Start adjustment 5
• In the "Available Functions:" window select "Init" and click on "Execute". The X-Iris is au-
tomatically opened to full format and the slot diaphragm is opened to maximum aperture.
Full format, X-Iris open 5
• Zoom must be disabled.
• Release fluoro and wait until generator has performed automatic adjustment.
• Switch fluoro off. The X-Iris is displayed on the monitor.
• Use the keys for opening and closing the X-Iris to set the diameter of the superimposed
circle to the size of the X-iris.
• In the "Available Functions:" window select "Open Pos - II. Full Format" and click on "Ex-
ecute".
• Close the status window by clicking on the OK button.
X-ray radiation!
See Chapter 1, Safety Information.
Use radiation protection! Wear a lead apron!
WARNING
