SIREMOBIL Iso-C SPR2-230.061.01 Page 22 of 30 Siemens AG
System Manual Rev. 13 12.04 CS PS 24 Medical Solutions
5 - 22 Adjustments / Programs
Checking the programmed values 5
Prerequisites
The
T
w
value is already programmed. Refer to Programming.
• Connect the service PC to the serial interface of the SIREMOBIL Iso-C.
• Start the service program.
• Select the Adjustment, Calibrations menu.
• Click "Yes" to answer the query.
• In the Combo box "Function Group:", select "Diamentor".
• In the window "Available Functions" , select the line "Start Diamentor Test" and click on
"Execute" .
• Close the status window by clicking on the Ok button.
• Respond to the query "Do you want to reset the unit" by clicking "No".
• Press the -0- key (reset key for fluoroscopic timer).
• The tested T
w
value is displayed on the monitor of the SIREMOBIL Iso-C.
• This value must match the programmed CONSTANT (Qt*Kg) value. Tolerance: + 5 %.
• By pressing the -0- key (reset key for fluoroscopic time) the test is repeated and is dis-
played again on the monitor.
Fig. 7
Checking the programmed values will activate the self-test in the
electronic system of the area dose product measurement device.
This serves to recalibrate the electronic system of the area dose
measurement device.
Potentiometer
NOTE
