Siemens SIREMOBIL Iso-C

Adjustments / Programs 5 - 15
Siemens AG SPR2-230.061.01 Page 15 of 30 SIREMOBIL Iso-C
Medical Solutions Rev. 13 12.04 CS PS 24 System Manual
• For the query "Do you want to reset the unit", click on "No". The X-Iris is automatically
closed to the smallest format.
Full format, X-Iris closed 5
• Briefly release fluoro. The X-Iris is displayed on the monitor.
• Use the keys for opening and closing the X-Iris to set the diameter of the superimposed
circle to the size of the X-Iris.
• In the "Available Functions:" window select "Close Pos - II. Full Format" and click on "Ex-
ecute".
• Close the status window by clicking on the OK button.
• For the query "Do you want to reset the unit", click on "No".
• The X-Iris remains in the minimum position.
• Zoom format is automatically selected.
Zoom format, X-Iris closed 5
• Briefly release fluoro. The X-Iris is displayed on the monitor.
• Use the keys for opening and closing the X-Iris to set the diameter of the superimposed
circle to the size of the X-Iris.
• In the "Available Functions:" window select "Close Pos - II. Zoom Format" and click on
"Execute".
• Close the status window by clicking on the OK button.
• For the query "Do you want to reset the unit" click on "No".
• The X-Iris is opened automatically.
• Zoom format remains selected.
Zoom format, X-Iris open 5
• Briefly release fluoro. The X-Iris is displayed on the monitor.
• Use the keys for opening and closing the X-Iris to set the diameter of the superimposed
circle to the size of the X-Iris.
• In the "Available Functions:" window select "Open Pos - II. Zoom Format and click on
"Execute".
• Close the status window by clicking on the OK button.
• For the query "Do you want to reset the unit", click on "No".
